Hydraulic Repair

Use case harden pins and bushings

If you have to replace your pins and bushings make sure your supplier or machine shop uses case hardened materials for both components.

If you use a soft material dust and dirt will embed into it, now this soft material will have fine particles like sandpaper in it, thus wearing out the harder material.

Example: Have you ever seen a worn hydraulic pump shaft and had wondered how could a rubber shaft seal wear a groove in a steel shaft.

Using case hardened material for both components reduces this problem for your pins.

Note: Most pins have some type of locking mechanism to keep them from turning to maintain this locking device (split pin, etc.) so that when the pin turns it only turns in the (greased) bushing.

At Hydrostatic Services we can custom make your case hardened pins and bushings from a large inventory of sizes.

Heat in your hydraulic system

An overheating hydraulic system is a cause for concern.

Heat is generated mostly in a hydraulic system when high-pressure oil drops to low pressure.

The higher the pressure drop the greater the heat generated.

The higher the volume of oil dropped the greater the heat generated.

Have you ever had your hydraulic repair technician arrive on a service call to find out it was only a blown o ring on a relief cartridge?

Your toolbox should contain an infrared thermometer.

It may help you in locating that weak or bad relief valve or diagnosing other failing components in your hydraulic system.

Your filtration micron (beta ratio) rating is more important than ever before.

Hydraulic oil contaminants are your enemy.

A free contaminant (bad) is a happy contaminant.

Trap them with your filtration, not between your expensive hydraulic components.

Proper filtration greatly decreases downtime.
You can never remove all the particles that hydraulic components generate.

But you can minimize how rapidly it destroys its components.

Today’s hydraulic components are working at higher pressures so that manufacturers of hydraulic pumps and components can make them physically smaller.

Higher pressure means that there is a smaller clearance of oil film between moving parts whereas a smaller particle of contaminant can become trapped.

Today’s equipment manufacturers are trying to reduce the cost to become more competitive

They do not always keep up with the needed filtration for prolonged life of components e.g. (after warranty).

Note: A lower (better) beta ratio of a filter also means that a filter has to be larger size (more $$$) to reduce back pressure (wasted horsepower) from the flow of hydraulic oil (wasted horsepower, wasted. $$$).

At Hydrostatic Services our sales staff and technicians can help you determine if adequate filtration is on your equipment.

Bearings do have a rated life.
Don’t let the bearings in your hydraulic system destroy your components.

Our technicians at Hydrostatic Services do consider bearing life when repairing your components.

Hydraulic Sales

Hydrostatic Services sales staff has more than100 years of combined hydraulic sales experience.

Helping their customers identify and purchase the correct component for their needs.

We Stock

  • Hydraulic gear pumps
  • Hydraulic vane pumps
  • Hydraulic piston pumps
  • Hydraulic gear motors
  • Hydraulic vane motors
  • Hydraulic piston motors
  • Hydraulic geroter motors
  • Hydraulic modular valves
  • Hydraulic directional control valves
  • Hydraulic cylinders (welded, tie rod, telescopic)
  • Hydraulic relief valves
  • Hydraulic joysticks and Electrical joysticks
  • Hydraulic pressure and temperature gauges
  • Hydraulic solenoid valves
  • Hydraulic power units (ac and dc)
  • Hydraulic filters (hydraulic, engine lube, air and fuel)
  • Hydraulic pressure and temperature switches
  • Hydraulic seals
  • Hydraulic pump drives
Hydraulic hoses (up to 2 inch 6 wire)
  • Suction hoses
  • Air conditioning hoses
  • Power steering hoses
  • Pressure wash hoses
  • Twin line hoses
  • Thermoplastic hoses
  • Stainless steel Teflon hoses
  • Hydraulic fittings and adaptors (jic, orb, npt, bsp, ors, orf, and metric) over 4800 line items
  • Quick couplers
  • Live swivels
  • Test couplers
  • Brass fittings
  • Pins and bushings
  • Electrical switches
  • Panel gauges
  • Pneumatic cylinders
  • Pneumatic valves
  • Pneumatic tubing
  • Pneumatic fittings and adaptors
  • Pneumatic gauges
  • Pneumatic filters
  • Pneumatic lubricators
  • Pneumatic regulators
  • Honed hydraulic cylinder tubing
  • Mechanical tubing, Steel line tubing
  • Aluminum tubing
  • Ductile iron
  • Rotocast bronze
  • Aluminum bronze
  • Induction chrome shafting
  • Bearings
  • Hardened steel bushings
  • Spherical ball bushings
  • D U bushings
  • Bronze bushings
  • Splined billets (hardened and soft)
  • Splined shafts (hardened and soft)
  • Snap rings (internal, external, spiral)
  • Cap screws
  • Springs
  • Cotter pins
  • Dowell pins
  • Split pins
  • Spiral pins
  • Skidder parts
  • Manual transmission parts
  • Differential parts
  • Planetary parts
  • Winch parts and cables
  • Driveline components
  • Drive Clutches
